R134a立式 DC 3600rpm-ASH
| 代表机型 | 排量 | 制冷量 | 转速范围 | 功率 | 能效比COP | 额定电压 | 冷冻机油量 | 压缩机质量 | 压缩机高度 | 排气管尺寸 | 回气管尺寸 | 备注 |
| (cc) | (W) | (rpm) | (W) | (W/W) | (V) | (ml) | (Kg) | (mm) | (螺纹规格) | (螺纹规格) | ||
| CVSR98D11-A33 | 9.8 | 1444 | 900~4500 | 456 | 3.17 | 24 | 340 | 5.6 | 191 | M22x1.5 | M24x1.5 | |
| CVSR108D11-A33 | 10.8 | 1609 | 900~4500 | 486 | 3.31 | 24 | 340 | 5.6 | 191 | M22x1.5 | M24x1.5 | |
| CVSR140D11-A33 | 14.0 | 2046 | 900~4500 | 646 | 3.17 | 24 | 340 | 6.4 | 206 | M22x1.5 | M24x1.5 | |
| CVSL170D11-A13 | 16.9 | 2422 | 900~3900 | 734 | 3.30 | 24 | 350 | 9.5 | 251 | M22x1.5 | M24x1.5 | |
| CVSR140D14-A33 | 14.0 | 2046 | 900~4500 | 620 | 3.30 | 60 | 340 | 6.4 | 206 | M22x1.5 | M24x1.5 |
